Product Description
The SEAFLO 22 series pumps are your best choice when looking for a high performance diaphragm pump at an economical cost.? Simple but highly versatile, the Seaflo 22 series pumps are perfect for fluid handing applications such as purification, light industrial, food and beverage,? agricultural, and automotive.? Additionally, it's packed with features and capabilities you'll never find in other pumps at this price point. The 22-series of diaphragm pumps are self-priming, can be run dry without harm and have an internal bypass feature which reduces pump cycling. It provides up to 1.4 gallons per minute. Features & Benifits: 1. Adjustable pressure switch from 17-120psi for OEM when needed. 2. By-pass reduces noise. Strain on the pipes and wear on the pressure switch. 3. Quite operation. Motor sounds not louder than your room fan running. 4. Hose connections with multiple fittings allow connection to any outlet. 5. Rubber feet for noise reduction for vibration. 6. Compact design and heavy-duty demand switch. 7. Can run dry.Other Details
2 YearsProduct Videos
Custom Field
Part Number PUMP-SFADP1-013-100-22
Voltage 12V
Open Flow(GPM/LPM) 1.3/5.0
Control Type Switch & By pass
Shut-Off Pressure(PSI/KPA) 100/690
Inlet 3/8 Inch Barb
Outlet 3/8 Inch Barb
Wire Connections 2-Pin/Leads
