Grundfos Submersible 4" Pump - SP 14-15 , 1x240V , Three Wire c/w Starter and Tesla Motor

Product Description

SP 14-15
Submersible borehole pump, suitable for pumping clean water. Can be installed vertically or horizontally. All steel components are made in stainless steel, EN 1.4301 (AISI 304), that ensures high corrosive resistance. This pump carries drinking water approval.

Liquid:
Pumped liquid: Water
Maximum liquid temperature: 40 °C
Liquid temperature during operation: 20 °C
Density: 998.2 kg/m³

Technical:
Pump speed on which pump data are based: 3450 rpm
Rated flow: 16.7 m³/h
Rated head: 91.8 m
Curve tolerance: ISO9906:2012 3B

Downloads:

1. Brochures

OPTIMISED-FOR-UNDERGROUND-PERFORMANCE_(SP)(Product brochure)

SP-Installation-quick-guide(Product brochure)

SP-Pump-performance-measuring(Product brochure)

2. Installation & operating instructions

Flow-Sleeves(Quick Guide)

Pt100_Pt1000(Quick Guide)

SP

3. Data booklets

SP-A_SP-submersible pumps-motors_and_accessories(Data booklet)

4. Service

SP-(Recommended spare parts)-Service_Kit_Catalogue

SP-7_9_11_14(Service instruction)

SP-11A_to_SP-14A(Service Instructions)
