Product Description
DESIGN HIGHLIGHTS
The PondMAX Waterfeature Pumps have been manufactured to provide you with the best quality pumps for your water feature. Visit our website to view our range of pond filtration, outdoor/underwater lighting, water treatments and general accessories.
• Long life Impellor Design – Ceramic shaft is wear resistant and self-lubricated by water
• Marine Compatible* see warranty disclaimer – No exposed copper.
• Tool-less Assembly - Easy maintenance. No special tools required.
• BSP Threaded inlet – Easy to connect an optional block pre-filter sponge
• In-line use.
• Built-in Flow adjuster.
• 10m outdoor cable.
• Pre-filter sponge compatible - Please note that there is a separate locking ring for pre-filter sponge usage (PV1200 only)
BENEFITS INCLUDE
• PondMAX Waterfeature Pumps are suitable for use in many different applications including fountains, waterfeatures, aquarium applications and hydroponics.
The pumps can be used in either submersible or in-line use applications.
• Your pump has a single moving part (an impeller set) enabling easy cleaning and maintenance.
• The motor is totally encapsulated in epoxy resin, ensuring safe operation under water.
• The pump has a robust bearing and shaft design so no Oil/grease lubrication is required.
• PondMAX pumps, that have plastic impeller parts and ceramic shafts, can be used in Marine applications as there is no exposed copper.
For Marine use, please see warranty disclaimer.
• PondMAX waterfeature pumps are continuous rated therefore are designed to operate 24/7.
• When using with a fountain kit, it is strongly recommended to purchase a optional block pre-filter sponge. This assists in straining the partials in the water, to assist the fountain nozzles becoming blocked up with debris. See your retailer for options.
PRODUCT SPECIFIC SAFEGUARDS
• Do not operate the pump without water at any time, permanent damage may occur.
• Waterfeature pumps are a magnetically driven centrifugal pump. Be sure the equipment is submerged completely in the water. If used in line, the pump must have adequate flooded suction at all times, therefore they cannot suck from a water level that is below the inlet level.
• The pump is designed to be used in a garden waterfeature or aquarium environment. It is not to be used in any other manner or purpose.
• The pump should only be used in clean water only. Do not use the pump in, or with, any chemicals such as a solvent or gasoline.
All PondMAX Submersible pumps are cooled by water flowing through the inside of the motor body. If the pump flow becomes restricted it will overheat and could cause permanent damage. Large tubing size is strongly recommended to deliver adequate water flow to cool the pump. The pump needs to be cleaned regularly to prevent the pump becoming blocked, thus causing the pump to overheat and burn out. This is not a warrantable event. It is strongly recommended not to select a pump that is too small for the job required. The flow rate through the pump needs to be enough so that a half of the rated max flow is kept running at all times.
