Product Description
The Lowara 16GS15-1 is a 4" multistage submersible bore pump from the e-GS Series, designed for water supply from drilled wells and cisterns, sprinkler irrigation, pressure boosting and fire-fighting applications.
The 16GS15 is designed around a nominal flow of 16 m³/h and operates at approximately 2900rpm. Its 8-stage hydraulic design is powered by a 1.5kW (2HP) motor and provides a total head of approximately 38.0 metres at zero flow, 30.6 metres at 10.2 m³/h, 27.6 metres at 12.3 m³/h, 22.1 metres at 15.6 m³/h, 16.4 metres at 18.6 m³/h and 9.2 metres at 22.0 m³/h.
The e-GS construction combines floating impellers with a front wear ring for resistance to sand abrasion, together with stainless steel upper and lower supports for corrosion resistance and durability. An integrated stainless steel non-return valve helps prevent reverse flow through the pump.
Key Specifications:
- Model – Lowara 16GS15-1
- Series – Lowara e-GS
- Pump Type – 4" Multistage Submersible Bore Pump
- Number of Stages – 8
- Nominal Flow – 16 m³/h
- Motor Power – 1.5kW / 2HP
- Operating Speed – Approximately 2900rpm
- Maximum Head at Zero Flow – Approximately 38.0m
- Head at 10.2 m³/h – Approximately 30.6m
- Head at 12.3 m³/h – Approximately 27.6m
- Head at 15.6 m³/h – Approximately 22.1m
- Head at 18.6 m³/h – Approximately 16.4m
- Head at 22.0 m³/h – Approximately 9.2m
- Delivery Port – Rp 2
- Maximum Pump Diameter – 99mm Including Cable Cover
- Maximum Permissible Sand Content – 150 g/m³
- Maximum Water Temperature – 35°C
- Integrated Non-Return Valve – Stainless Steel
- Applications – Bore Water Supply, Cistern Water Supply, Sprinkler Irrigation, Pressure Boosting & Fire-Fighting
