Product Description
The Davey XP45T is a single stage jet assisted pressure pump supplied with a Torrium2 controller for automatic water pressure control. Designed for small to average size homes, cottages, weekenders, caravans and boats, it is suitable for domestic water supply, pressure boosting and automatic water transfer.
The corrosion resistant TEFC motor drives a single stage jet assisted centrifugal pump and is designed for frequent starting. Built-in thermal overload protection helps protect the motor against damage due to jamming, while the corrosion resistant construction provides dependable performance for domestic water applications.
The Torrium2 controller provides automatic pump operation by responding to water demand, starting the pump when pressure falls and stopping it when demand ceases. This provides an automatic pressure system without the conventional pressure switch and 8 litre pressure tank configuration.
Key Specifications:
- Model – Davey XP45T
- Product Type – Single Stage Jet Assisted Pressure Pump
- Controller – Davey Torrium2
- Pressure Control – Automatic
- Supply – 220–240V AC
- Frequency – 50Hz
- Nominal Speed – 2850rpm
- Input Power (P1) – 0.62kW
- Output Power (P2) – 0.45kW
- Full Load Current – 2.8A
- Motor Type – TEFC
- Motor Enclosure – IP55
- Insulation Class – Class F
- Maximum Suction Lift – 6m
- Inlet – 25mm (1") Female BSP
- Outlet – 25mm (1") Male BSP
- Maximum Liquid Temperature – 50°C
- Maximum Ambient Temperature – 50°C
- Motor Protection – Built-In Thermal Overload Protection
- Pump Casing – Glass Filled Nylon
- Impeller – Glass Filled Polycarbonate
- Pump Shaft – 304 Stainless Steel
- Warranty – 2 Years
- Applications – Domestic Water Supply, Pressure Boosting & Automatic Water Transfer
Download:
XP45T_cw_Torrium2_Controller_Datasheet
XP45T_cw_Torrium2_Controller_Installation_and_Operating_Instructions
