Product Description
The Orange Pumps SJ100-PM10 is a stainless steel jet pressure pump system designed for automatic water supply around the home, garden or farm. The SJ100 jet and venturi design increases pressure from the impeller and assists with purging air from the pump casing, making it suitable for installations with long suction lines or suction lift.
The system includes a PM10 PressMatic controller that automatically starts the pump when pressure drops and stops it when water flow stops. The controller also provides loss of prime and run-dry protection, a flow stop function to reduce cycling, a built-in check valve and a 360° swivel connector.
The SJ100 is powered by a 400W heavy-duty TEFC motor and operates on 220–240V power. The PM10 controller has a 10 metre cut-in setting, and the complete SJ100-PM10 system is rated for up to 3 outlets.
Key Specifications:
- Model – Orange Pumps SJ100-PM10
- Product Type – Stainless Steel Jet Pressure Pump System
- Pump Model – SJ100
- Pump Design – Jet & Venturi
- Power – 400W
- Supply Voltage – 220–240V
- Full Load Current – 1.5A
- Motor Type – TEFC
- Motor Enclosure – IP55
- Pump Inlet – 1"
- Pump Outlet – 1"
- Shaft Seal – Carbon Ceramic
- Maximum Fluid Temperature – 65°C
- Controller – PM10 PressMatic
- Controller Cut-In – 10 metres
- Recommended Outlets – 3
- Pump Warranty – 3 Years
- Controller Warranty – 2 Years
- Applications – Home, Garden & Farm Water Supply
