Product Description
The Davey DCS55M is a double case submersible greywater pump designed for dirty water pumping, sump emptying, septic effluent disposal and wastewater containing small soft solids. It is also suitable for partially submerged applications.
The DCS55M is the manual-operation version without a float switch. Its open semi-vortex centrifugal impeller handles small soft solids with reduced susceptibility to blockage. The double case design directs the full discharge flow past the internal motor shell for improved motor cooling, while the 304 stainless steel outer casing and strainer provide corrosion resistance and durability.
With a maximum flow of approximately 300 L/min and maximum head of approximately 12 metres, the DCS55M provides reliable performance for greywater, effluent and dewatering applications. The single-phase motor includes automatic thermal overload protection and is supplied with a 10 metre oil-resistant power lead and 3-pin plug.
Key Specifications:
- Model – Davey DCS55M
- Pump Type – Double Case Submersible Greywater Pump
- Operation – Manual
- Maximum Flow – Approximately 300 L/min
- Maximum Head – Approximately 12m
- Maximum Soft Solids – Less Than 10mm
- Impeller Type – Open Semi-Vortex Centrifugal
- Impeller – Cast Iron
- Outlet Connection – 2" Female BSP
- Suction Inlet – 304 Stainless Steel
- Outer Casing – 304 Stainless Steel
- Pump Casing – Cast Iron
- Pump Shaft – 304 Stainless Steel
- Motor Shell – 304 Stainless Steel
- Handle – 304 Stainless Steel
- Fasteners – 304 Stainless Steel
- Motor Protection – Automatic Thermal Overload
- Output Power – 0.55kW
- Supply – 220–240V Single Phase, 50Hz
- Full Load Current – 4.0A
- Motor Speed – 2850rpm
- IP Rating – IPX8
- Insulation Class – Class F
- Power Cable – 10m HO7RN-F Oil Resistant Lead
- Plug – 3-Pin Plug
- Net Weight – 25kg
- Dimensions – 430mm Overall Height x 192mm Diameter
- Warranty – 2 Years
- Applications – Dirty Water Pumping, Sump Emptying, Septic Effluent Disposal, Greywater, Wastewater & Partially Submerged Applications
