Product Description
The Davey HP85-08T is a horizontal home pressure system fitted with a Torrium2 controller for automatic water supply. It is designed for pumping clean, non-volatile liquids without fibres or solids in applications including household water supply, irrigation, water transfer, washing systems and pressure boosting.
The pump features a reliable twin stage impeller design with stainless steel construction and a carbon/ceramic mechanical seal. Its TEFC motor is rated IP55 and includes an automatically resetting thermal overload for protection against high operating temperature and high current draw.
The HP85-08T uses a 0.8kW output motor operating on 220–240V single phase power. The Torrium2 provides constant flow control and adaptive operation, while the system features a 1¼" female inlet and 1" male outlet.
Key Specifications:
- Model – Davey HP85-08T
- Product Type – Horizontal Pressure Pump with Controller
- Controller – Torrium2
- Pump Design – Twin Stage
- Supply Voltage – 220–240V ±6%
- Supply Frequency – 50Hz
- Phase – Single
- Speed – 2850rpm
- Full Load Current – 5.1A
- Locked Rotor Current – 18.0A
- Input Power (P1) – 1.14kW
- Output Power (P2) – 0.8kW
- Motor Type – TEFC
- Enclosure Class – IP55
- Insulation Class – Class F
- Maximum System Pressure – 450kPa
- Maximum Suction Head – 6 metres
- Maximum Ambient Temperature – 50°C
- Water Temperature – 1–50°C
- Inlet – 1¼" Female
- Outlet – 1" Male
- Net Weight – 10.8kg
- Warranty – 2 Years
- Applications – Household Water Supply, Irrigation, Water Transfer, Washing Systems & Pressure Boosting
