Product Description
Applications :
• Grey and black water pumping
• Sump emptying
• Septic effluent and sewage disposal
• Pumping of waste water with soft solids in suspension
Specifications :
PUMP
Heavy duty shredding and grinding ring at inlet. Centrifugal design, open impeller. Double Mechanical shaft seal in oil bath. Hard faced Silicon Carbide/Ceramic seal on pump side. Sand slinger lip seal for added protection. Oring casing sealing. Corrosive resistant stainless steel and quality heavy duty powder coated cast iron pump parts.
MOTOR
2 pole, 2900rpm 50Hz 240V single phase or 415V three phase. Submersible with IPx8 enclosure. Class F insulation. 10 metre HO7RN-F oil resistant power lead and seal sensor lead fitted with bared wire lead ends for easy connection to power supply terminations. Seal sensor leads fitted for easy connection to a protection relay to enable timely repairs prior to motor damage. Not fitted to D75G/GA or DT08G models. Protected against both high operating temperatures and high current by a built in automatically resetting thermal overload.
Benefits :
• Able to pump soft organic solids, sanitary products, thin rubber products and even some textiles in
suspension, by shredding to a slurry
• Open impeller prevents blockage of the pump by small solids in the slurry
• High heads and small solids allow connection to small discharge pipe systems, especially suited to
pumping waste water to pressure sewer mains
• Silent operation
• Quick and easy installation
• Hose tail supplied with every pump
• Low maintenance
• Fully repairable
• Mounting feet with rubber cushions fitted for a firm and stable positioning during installation and
operation for D75G/ GA, DT08G, D120G/A, D150G/A, DT12G & DT15G.
• Adaptable to slide rails – see accessories
